Oracle E-SBC Virtual Installation
E-SBC 9.1
V1019984-01.zip -> nnSCZ910-img-vm_vmware.ova
Baud rate: 115,200 bits/second
Data bits: 8
Parity: No
Stop bit: 1
Flow control: None
Bootprarm: leave it default
Password: acme
Newpassword:cisco,123
Enable
Password:packet
Newpassword:cisco,123
Setup product: 1 - 5 - d
e-sbc-a# setup product
--------------------------------------------------------------
WARNING:
Alteration of product alone or in conjunction with entitlement
changes will not be complete until system reboot
Last Modified 2022-04-28 14:23:51
--------------------------------------------------------------
1 : Product : Enterprise Session Border Controller
Enter 1 to modify, d' to display, 's' to save, 'q' to exit. [s]: s
save SUCCESS
e-sbc-a#
e-sbc-a#
e-sbc-a# setup entitlements
----------------------------------------------------------------
Entitlements for Enterprise Session Border Controller
Last Modified: Never
----------------------------------------------------------------
1 : Session Capacity : 0
2 : Advanced :
3 : STIR/SHAKEN Client :
4 : Admin Security :
5 : Data Integrity (FIPS 140-2) :
6 : Transcode Codec AMR :
7 : Transcode Codec AMR Capacity : 0
8 : Transcode Codec AMRWB :
9 : Transcode Codec AMRWB Capacity : 0
10: Transcode Codec EVS :
11: Transcode Codec EVS Capacity : 0
12: Transcode Codec OPUS Capacity : 0
13: Transcode Codec SILK Capacity : 0
Enter 1 - 13 to modify, d' to display, 's' to save, 'q' to exit. [s]: 1
Session Capacity (0-512000) : 8000
Enter 1 - 13 to modify, d' to display, 's' to save, 'q' to exit. [s]: 2
Advanced (enabled/disabled) : enabled
Enter 1 - 13 to modify, d' to display, 's' to save, 'q' to exit. [s]: d
----------------------------------------------------------------
Entitlements for Enterprise Session Border Controller
Last Modified: Never
----------------------------------------------------------------
1 : Session Capacity : 8000
2 : Advanced : enabled
3 : STIR/SHAKEN Client :
4 : Admin Security :
5 : Data Integrity (FIPS 140-2) :
6 : Transcode Codec AMR :
7 : Transcode Codec AMR Capacity : 0
8 : Transcode Codec AMRWB :
9 : Transcode Codec AMRWB Capacity : 0
10: Transcode Codec EVS :
11: Transcode Codec EVS Capacity : 0
12: Transcode Codec OPUS Capacity : 0
13: Transcode Codec SILK Capacity : 0
Enter 1 - 13 to modify, d' to display, 's' to save, 'q' to exit. [s]: s
SAVE SUCCEEDED
e-sbc-a#
Reboot
Config t
System
http-server
name clab
state enabled
realm
ip-address
http-state enabled
http-port 80
https-state disabled
https-port 443
http-interface-list REST,GUI
http-file-upload-size 0
tls-profile
auth-profile
last-modified-by admin@10.254.169.197
last-modified-date 2022-04-28 15:17:41
Done
Exit
Verify-config
Save-config
Activate-config
